Benchtop pH/mV/°C Meter (Model: HV-10-PHA)
Benchtop pH/mV/°C Meter
Model: HV-10-PHA
This is a high precision pH meter with large backlit LCD display. The meter can display many useful prompt messages to helps you quickly and easily measuring the samples.
TECHNICAL SPECIFICATION: -
• During the pH mode, up to 5 points push-button calibration with auto- buffer recognition.
• Selectable pH buffer standards and temperature units.
• Automatically calculates and displays electrode slope after calibration.
• Automatic Temp. Compensation (ATC) ensures highly accurate measurement over the entire range.
• Calibration due reminder prompts you to calibrate the meter regularly.
• During ORP mode, Single point offset calibration allows user adjusts displayed value to a known standard.
• Absolute or Relative millivolt (R.mV) measurement provides accurate ORP readings.
• Automatic endpoint function freezes the stable measured values for easy reading and recording data.
• Setup menu lets user customizes buffer standards, calibration points, stability conditions, resolution, temperature units, date and time to meet measurement requirements.
• Reset function can resumes all settings to factory default values.
• Expanded memory stores and recalls up to 500 readings.
• Built-in real-time clock stamps stored data to meets GLP standards.
pH Range - -2.000~20.000pH
pH Accuracy - ±0.002pH
pH Resolution - 0.001, 0.01, 0.1pH (Selectable)
mV Range - ±1999mV
mV Accuracy- ±0.2mV
mV Resolution - 0.1, 1mV (Selectable)
Calibration upto - 5 points
pH Buffer Option- USA (pH1.68,4.01,7.00,10.01,12.45), NIST (pH1.68,4.01,6.86,9.18,12.45) DIN (pH1.09,4.65,6.79,9.23,12.7) OR User Define
Calibration due reminder - 1 to 30 days or Off
Temp. Range - 0~105°C, 32~212°F
Temp. Accuracy- ±0.5°C, ±0.9°F
Temperature Compensation- 0~100°C, 32~212°F, Automatic or Manual
Auto-Off Manual or Automatic- (10, 20, 30 minutes after last key pressed (Selectable)
Memory - 500 readings with date & time
Power Supply - DC Adaptor, Using AC 220V,50/60Hz
Dimensions LxWxH (mm) - 313 × 260 × 195mm
Weight - 2.1kg
INTERNAL CODE: - KD.2328.250606
