ADVANCED TRINO MICROSCOPE (Model: HOX- 620-NE)
ADVANCED TRINO MICROSCOPE
(Model: HOX- 620-NE)
Technical Specifications: -
Optical system: Infinity Super PLAN Achromatic color correction optical system.
Body structure: A high-quality aluminum alloy Single mold stand with hands at rest for enhanced comfort and stability.
The surface is sprayed with nano silver ion antibacterial coating to
effectively inhibit growth of microorganisms.
The microscope has ECO energy saving and (LIM) light intensity
management function, supports stepless brightness setting.
Lighting system: Built-in SUPER-LED Daylight simulated LED
lighting system with constant color temperature of 4500K, light
source life of more than 60,000 hours;
Focus system: Coaxial Synchronised coarse & fine focusing system.
The assisted fine focus has a minimum step accuracy of up to 1μm
and a maximum stroke of 25mm. It has tension adjustment and anticollision height limiter.
Stage: Rackless X axis, double plate stage size 200 x 250mm, X/Y
travel range 128mm x 80mm. Low drive right hand movement
controls. Hard coated surface for scratch resistance.
Slide clip: The slow-rebound left-hand section clamp supports single
slides and can carry heavy samples such as counting chambers.
Condenser: Pre-centered Kohler condenser with aperture indicator
scale marking NA 0.1~1.1, supports bright field, polarized light and
other contrasting techniques.
Observation tube: 30° Siedentopf trinocular observation tube with
50/50 split with interpupillary adjustment range of 48-75mm.
Eyepiece: 30mm bore wide field eyepiece with magnification 10x,
FOV 22mm with +/-5 diopter adjustment. 15x, 20x and 30x eyepieces.
(Optional).
Nosepiece: The microscope body has a built-in inward-inclined
quintuple coded objective nosepiece with proper click stops and RMS international standard objective thread interface.
Objective: Super-Plan Infinity objectives: 4X (NA ≥ 0.10, 10X (NA ≥ 0.25), 20X (NA ≥ 0.40), 40X (NA ≥ 0.65), 100X (NA ≥ 1.25), Anti-fungal & Anti-reflection treated.
Anti-mold device: Optical imaging components such as observation tubes, eyepieces, and objectives have all been treated with antifungal and anti-mildew treatments.
Environmental friendly: All optical components used are made of environmentally friendly lead-free glass and comply with RoHS environmental directives.
Electronics: Universal input 100V- 240V AC, 50/60Hz, built-in voltage stabilizer and built-in 3 inch LED display which shows the illumination intensity and the objective in position.
Accessories (Optional):
Pointers & Micrometer reticules
Wooden box
Auxiliary objectives and eyepieces
Slider/Turret Type Phase Contrast attachment
Polarizing attachment
Single filter/ Dual filter Fluorescent attachment
Dark Field attachment
Application specific USB/HDMI cameras
Package Contents:
10ml Immersion oil bottle
User manual
Nylon dust cover & cleaning cloth
Styrofoam casing
INTERNAL CODE: - KD.PRV/25719
