Conductivity/TDS Meter (Model No: HVO-CM-20H)

Conductivity/TDS Meter

Specification:

• Conductivity Range - 0~20.0, 200.0, 2000µSlcm, 20.00, 200.0mSlcm (5 Auto range)
• Conductivity Resolution: 0.01, 0.1, 1

• Conductivity Accuracy: ±0.5% F.S.
• Calibration Points: Up to 3 points
• Calibration Solutions: 10 µS/cm, 84 µS/cm, 1413 µS/cm, 12.88 mS/cm, 111.8 mS/cm (any three)
• TDS Range: 0~10ppt (Max.200 ppt, depending on factor setting & conductivity range)
  TDS Accuracy: + 1% F.S

• TDS Factor: 0.1 to 1.0 (Default 0.5)

• Temperature Range: 0 to 105°C (32 to 221°F)
• Temperature Resolution: 0.1°C (0.1°F)
• Temperature Accuracy: ±0.5°C (±0.9°F)
• Temperature Compensation: 0 to 100°C, Manual or Automatic

• Cell Constant Option: K= 0.1,1, 10
• Normalization Temperature: 25°C
• Memory: up to 100 Readings
• Reset Function: Yes
• Interface: USB
• Connector: 6Pin Mini Plug
• Operating Temperature: 10 to 40°C
• Relative Humidity: <80%
• Display: LCD with White Back Light
• Display Size: 25x100cm
• Power Requirements: Adaptor, Using AC 220V, 50/60Hz

 Salient Features

• Measuring Mode - Conductivity, TDS, Temperature

• 1 to 3 points calibration with automatic recognition for conductivity standards.

• Auto ranging for Conductivity & TDS Measurements

• Selectable cell constant, reference temperature

• Automatic temperature compensation ensure accurate readings over the entire range

• Auto read function senses and locks the measurement endpoint.

• Setup menu allows setting the number of calibration points, temperature unit, etc.

• Reset function automatically resumes all settings back to the factory defaults.

• Expanded memory stores or recalls up to 100 readings.

• USB Interface
