Contact Tachometer (Model No. HVO-9224-213)
Contact Tachometer
Specification:
- Measuring Range:
Rotary Speed: 0.5~19999RPM
Line Speed: 0.05~500m/min
Line Length: 0.05~99999m
- Resolution:
Rotary Speed:
0.1RPM (range 0.5~999.9RPM
1RPM (range 1000~19999RPM)
Line Speed:
0.01m/min (range 0.05~99.99m/min)
0.1m/min (range 100~500m/min)
Line Length: 0.02m
- Accuracy:
Rotary Speed:
±(0.4%n+1d) RPM (n<300RPM)
±(0.05%n+1d) RPM (n>300RPM)
"n" is rotary speed, 'd' is resolution
Line Speed: ±(1%+1d)m/min 'd' is resolution
Line Length: ±(1%+1d)m 'd' is resolution
- Sampling Time: 0.8s (above 60 RPM)
- Operation Temperature: 0~40°C
- Power Supply: 3xAAA batteries
- Dimension: 171x71x35mm
- Weight: 162g
Features:
- Can measure rotary speed, line speed and line length
- Automatically save the maximum value, minimum value and the last value, 96 data can be stored during continuous measurement
- With backlight display
Standard Delivery:
- Main Unit: 1Pc
- Wheel with 0.1m perimeter Clamping sleeve: 1Pc
- Cone head: 1Pc
- Small cone head: 1Pc
- Cone cavity head: 1Pc
- Battery (AA): 3Pcs
