HOVERLABS Fully Automatic Rotary Microtome

MODEL: HV-HSM-2020A

With a Section Thickness of 0.5-60um this state of the art Fully Automatic Rotary Microtome is the result of our 28 years of endeavour to improve model over model. All our microtomes are manufacturer adhering to stringent quality control norms and tested on over 200 parameters ensuring long lasting precise performance with peace of ownership and operation.

SPECIAL FEATURES :

• Rust proof construction.
• Lockable hand wheel at any position allowing change of blade/specimen easier and safe.
• Lateral knife adjustment to ensure that the entire width of the blade is used without releasing the blade clamping mechanism.
• Large storage capacity on the top of the instrument for easy access of tools.
• Finger protection guard to protect the used from any injuries caused due to blade.
• Robust and stable base plate for maximum stability to the microtome.
• Ergonomic and user friendly design.
• Section Waste tray to collect section waste and is easily removable for cleaning purposes.
• LCD Display with Feather Touch Keypad
• Slicing/Trimming Mode
• TOUCH Fast Forward/Backward Function
• TOUCH Increase/Decrease Section Thickness
• TOUCH Section Counter/Section thickness display
• Motorized Feed & Coarse Drive in two speeds.
• Sectioning Mode: Semi-automatic, Fully automatic.
• precision micrometer feeding system with 3-4 nodes of sectioning
• adjustable specimen retraction system
• electromechanical feed system for fine and trimming section thickness and forward and backward specimen movements via stepping motor.
• able to provide section thickness range of 0.5 micron to 100 micron.
• trimming thickness feed via precision stepping motor for 5 micron to 100 micron.
• knife holder to hold both high profile & low profile disposable blades with UCC & SSC clamps.
• Horizontal feed range 24-28mm and vertical specimen stroke length 65+/-mm
• Operable at 230V, 50Hz

TECHNICAL SPECIFICATIONS:

Section thickness setting: 0.5-60µm

Setting values : from 0.5µm-2µm in 0.5µm increments

From 2µm- 20µm in 1µm increments

From 20µm-60µm in 5µm increments

Trimming Thickness Setting: 1µm-100µm

Setting values : from 1µm-20µm in 1µm increments

From 20µm- 60µm in 5µm increments

From 60µm- 100µm in 10µm increments

Minimum Setting value: 0.5µm

Object feed: 30mm

Max. Specimen Size: 50X50mm

Sectioning speed range: Adjustable

Operation: Semi-automatic, Fully automatic.

Nominal Voltage: 220V, 50Hz/110V, 60Hz

Other features are mentioned in our catalogue
