Double Surface LED Phototherapy Unit (Model No: HV-151DC)

Double Surface Phototherapy (LED Based)

Specification

• Light unit have made of easily cleanable plastic material. It have fanless technology.
• The light source have a high life minimum of 1,00,000 hours
• Spectral Irradiance of minimum 35 – 45µW·cmˉ²·nmˉ¹ at 45 cm distance between bed and light unit.
• Wavelength have between 420 – 460 nm, and have free from UV and IR radiation. Effective surface area have at least 250 *500 mm within a irradiance ratio of 0.4.
• It have Digital Timer for monitoring therapy hours (resettable) & lamp usage hours (non resettable).
• It have Smooth Height adjustment mechanism with adjustable height. It have Smooth light unit tilting mechanism.
• Minimum height have approximately 1100 mm from the floor to use near the mother bed. Maximum height have approximately 1600 mm from the floor to use with the incubator.
• It have Electric supply: Universal Power supply 100V –240V AC, 50Hz to 60Hz with a power rating of 45W (Max).
• Coating have Epoxy/powder coated body for scratch and rust prevention and PU (Poly Urethane) coating for plastic.
• It have Three castors; two rear castors provided with brakes.
• The base of the unit have such that it will go beneath any Incubator/bed/trolley, with minimum of 100 mm floor clearance.
• Light intensity from blue LED’s have consistent across the treatment footprint at any angle of head tilt.
• Have equipped with white light for the observation purpose. It consists of backlit LCD.
• It have coverage of maximum surface area at any angle is 1800sqm.
• It have slim sleek look for less space consumption and can be easily combined with other NICU equipment (Warmer/ Incubator).

Product Internal Code: 8604
