Forced Draft Tray Dryer (Model No. HVO-MT-17)

Forced Draft Tray Dryer (Model No. HVO-MT-17)


  • Rs. 120,434.00

Forced Draft Tray Dryer


The set-up is designed to demonstrate and stimulate the moisture removal by heat under forced draft action created by hot air stream.

The set-up consists of an insulated double wall chamber. Inside the chamber a tray is attached directly to an electronic weighing balance, which is fitted on top outside the chamber. Material for drying is placed in the tray and regular loss of weight is monitored. Air from blower passes through heating chamber to produce hot air works as the drying agent entered from one side of the chamber and leave the chamber from other side removes the moisture from the tray. An arrangement is made to vary and measure the airflow rate. A digital temperature controller is used to control and measure the temperature of air stream.


  • Determination of rate of drying of wet sawdust under different conditions of temperature and air flow


  • Superb Painted structure
  • Simple to operate & maintain
  • Compact & stand alone set up

Utilities Required

  • Electric supply: 230 +/- 10 VAC, 50 Hz, single phase.
  • Material: Saw dust @ 1Kg.
  • Anemometer: Air flow measurement

 Technical Specification

Drying Chamber

Material Stainless Steel size 20 x 20 x 25cm insulated by Ceramic wool and housed in a MS Chamber


Material Aluminum / Stainless Steel

Weighing Balance

Digital, 0-500 gm of + 1 gm resolution

Hot Air Circulation

FHP blower, Arrangement is done to vary the air flow rate.

Air flow measurement

Compatible capacity


Nichrome wire heater

Control Panel

Digital Temp. Controller: 0-199.9°C, (For air heating chamber) On/off switch, Mains Indicator etc.
