HOVERLABS Fully Automatic Cryostat Microtome

HOVERLABS Fully Automatic Cryostat Microtome

HOVERLABS Online

  • Rs. 589,000.00
  • Save Rs. 141,000
8

Description

 (Double Compressor)

Model No. – HV-HSCM-1090A Make – HOVERLABS

SPECIAL FEATURES :

  • Motorized Feed Drive.
  • Dual Compressor for rapid freezing.
  • Arbitrary Switching between trimming & Sectioning.
  • Adjustable cutting angle.
  • Portable with 4 castors.
  • UV Sterilization.
  • Automatic and manual defrosting.
  • Blade Holder for finger safety.
  • Enclosed drainage system.
  • Anti-roll device.
  • Section counter.
  • Frost free encapsulated microtome assembly.
  • Visible operating parameters at all times.
  • User friendly control panel.

TECHNICAL SPECIFICATIONS:

Section Thickness Range  :1µm-60µm

Setting Values: 1µm-10µm in 1µm increments.

10µm-20µm in 2µm increments

 20µm-60µm in 5µm increments.

Trimming Thickness Range: 10µm-100µm in 10 µm increments.

Sectioning Speed Low: adjustable

Minimum Setting Value: 1µm

Vertical stroke: 65mm

Specimen horizontal feed: 25mm

Motorized coarse feed: 480 µm/sec.

Specimen retraction: 5-75 µm, in 1 µm increments.

Specimen Orientation: x- and y-axes   : universal 8o

Cryo Chamber Temp: -1 to -30oC Adjustable.

Cooling Downtime to -30oC.

Max. Specimen size             : 35x35mm.

Quick Freeze Shelf: < – 50oC

Chamber Defrosting: Programmable or manual.

Lowest Temp. of Pettier Unit: – 50oC.

No. of Freezing Stations: 10.

Voltage: 220V.
