Touch Screen Auto Biochemistry Analyzer (Model: HV-1200)

“HOVERLABS” Touch Screen Auto Biochemistry Analyzer

Model: HV-1200

Technical Specification:

For End Point, Kinetic, Fix Point, Multi Standard. Quartz flow cell system. Built in Thermal printer with graphics capability. Up to 250 test items. 4.3, inches Touch Screen LCD display, Wavelengths: 340,405,505,546,578,630, + 2 free positions, built thermal printer, Peltier Controlled thermostat, open reagent system, user friendly.

- Test Method: End Point With Standard/Factor Two Point Kinetics (Fixed Time) Multipoint Kinetics

Multi standard up to 8 standards Biochromatic, Dual Wavelength Absorbance Coagulation

- Optical System: Principle: Photometric Analysis with Interference Filter

Absorbance Range: 0.0000-3.0000 (Linearity: ±1%,

Repeatability: 0.001,

Resolution: 0.0001) Spectral

Range Selection: Automatic Via Filter Wheel Wavelengths: 340, 405, 450, 505, 546, 578, 630 nm + 2 Free

Positions, ± 2 CML Precision Light Source: 6 V 10 W Long Life Tungsten Halogen Lamp Detector: Photodiode

- Thermal System: Peltier Regulated 25°C, 30°C, 37°C & Room Temperature

Accuracy: ± 0.3°C

- Cuvettes: Flow Cell: Quartz 32 μl

Path Length: 10 mm

Removable Cuvette (Square and round)

- Printer: Inbuilt Thermal Printer (57mm) Optional External Printer

- Display & Input System: 7.0-inch color touch screen External Keyboard, Mouse facility

- Suction System: Pressure Auto releasing Peristalic Pump Suction Volume: 300 μl to 3.0 μl

Air Column facility after each sample to avoid carry over.

- Test Parameter, Storage & CPU: Test Parameters: Up to 300 2,00,000 test results with editable patient information

Storage of Quality Control And standard results DDR2 SDRAM: 1 G bit Flash: 256 MB ARM Cortex A8, 720 MHz

- Operating Conditions: Temperature: 10°C-37°C

Relative Humidity: <85%

- Power Requirement: Voltage: 100-240 V AC (Auto Adaption)

- Dimensions: 400x300x160 approx.

- Weight: 6kg approx.

INTERNAL CODE: - KD. 2458.25730
