Low Temperature Refrigerated Liquid Bath (Model No. HV-142)

Low Temperature Refrigerated Liquid Bath (Model No. HV-142)


  • Rs. 65,680.00

Low Temperature Refrigerated Liquid Bath

Technical Specifications:

Stainless Steel. Lid is also double walled properly insulated and is with locking facility. Whole unit is mounted on a sturdy angle iron frame The cooling coils are brazed to the outer side of S.S. chamber thus ensuring perfect and uniform cooling. Insulation is done with thick glass wool to prevent any temp. loss. For attaining the temp. below ambient, the refrigeration is done through CFC FREE hermetically sealed compressor and & for attaining the temp. above ambient, heating is done with immersion type heating element .Fitted with stirrer for temperature uniformity throughout the chamber. Temperature range is from -10 deg C. is controlled by Dual Display Microprocessor PID Digital Temperature Indicator cum Controller with a accuracy of ± 0.5° C Digital temp. To work on 220/230 volts AC supply. The unit is also fitted with a FHP PUMP for circulating the cooled liquid to an external source such as condenser coils, etc. PUFF insulation in the chamber & can be used as a circulating water bath in external instruments

  • Chamber Size In mms : 500 x 250 x 250
  • Capacity (L) : 32.5 L
