Moisture Analyzer (Balance) (Model No. HVO-MB SERIES)
Moisture Analyzer (Balance)
Moisture Analyzer has different names, such as Moisture Balance or Moisture Meter. This device consists of two main parts: a weighing unit and a heating unit that uses Infrared Halogen Technology. Its main purpose is to determine the moisture level in a sample by using the loss on drying principle.
Specification
- Display Information: % Moisture, %of dry substance, diagram graph, ratio, %Atro moisture, %Atro Dry, %gm/ltr.
- Temperature Range: Max to 175ºC (Optional 250ºC)
- Maximum Time Selection: 999.9 min
- Heating Source: Infra-Red Halogen/ Temperature Range 30ºC to 175ºC
- Temperature Increment: Interval 1ºC
- Heating Profile: Standard, Rapid, Step, Gentle & High Temperature
- Switch Off Criteria: Automatic, Manual timed, User DEF G/T, User DEF% U/T, Intelligent
- Menu Language: English
- Pan Size: 95 Ø - H:8 mm
- Statistics: Method wise for each individual 40 methods or Batch wise for each individual 100 batches for last 9999 results
- Data Storage: Last 9999 Moisture Determination results
- Auto Method Development: Intelligent
- Method Memory: 40
- Batch Memory: 100
- Compile: Yes (Method Linking)
- Standby Temperature: 30ºC to 100ºC
- Display: Graphical Display with LED Backlit
- Data Connection interface: RS 232C Bidirectional, USB Ethernet, PS2
- Print: GLP / GMP Compliant, User Configurable
- Test: Weighing and Heater
- Quality Management- Weight in Assist: Yes
- Quality Management- Password: Method, Setting, Print Format, Data Delete, Calibration, Drying
- Power Supply: 230V/50Hz or 115V/60Hz
- Power Consumption (W): Max 415
- Principle : Loss on Drying (LOD)
