Multipara Monitor (Model No: HV-1210)

Multipara Monitor

Specifications:

• High resolution 12.1" colour TFT display with multi channel waveform display.
• Parameter display- SpO2-PR, NIBP, ECG, RESP, 2-TEMP.
• 2400 NIBP measurement data can be stored and recall.
• Data and waveforms colour can be stored & recall.
• Built-in high energy rechargeable lithium battery.
• ECG waveforms of 7 leads display on the same screen.
• 480 hours graphic and tabular trends of all parameters.
• 71 alarm events of all parameters recall.
• Battery backup-2 hours.
• Data storage.
• Dimension=314 X 264 X 145 mm.
• Weight: 3.8 kg

Spo2

• Measurement Range: 0-100%

• Accuracy for Spo2: 2% {for 70-100%} and unspecified for 0-69%
• Pulse Rate
• Range: 30-250 bpm. Accuracy for PR: 3 bpm.
• NIBP
• Parameter Range: Systolic: 40-275 mmHg, Diastolic: 10-215 mmHg, Mean: 20-165 mmHg.
• Modes: Manual/auto/STAT with Oscillometric method.
• ECG
• Gain 2.5mm/mv,5.0mm/mv,10mm/mv,20mm/mv Led mode: 3 lead ors lead.
• Lead Selection: I,11, lll, avR, avL, avF and V.
• Heart red Rate Range: Adult: 35-300 bpm, Pediatric / Neonatal: 15-350 bpm.
