Portable Leeb Hardness Tester (Wired Probe D) (Model No. HVO-HDT-CB320)

Portable Leeb Hardness Tester (Wired Probe D) (Model No. HVO-HDT-CB320)


  • Rs. 71,862.00

Portable Leeb Hardness Tester (Wired Probe D)


  • Probe Included: Wired Probe D
  • Resolution: 1HLD/1HV/1HB/0.1HRC/0.1HRB/0.1HRA/0.1HS/1MPa
  • Accuracy: ±6 HLD (When HLD=800)
  • Output: USB
  • Measurement Range: HL 170-960/HRC 1.3-74.7/HRB 1.2-139.7/HB 28-1027/HV 45-1221
  • Applicable Materials:

1. Steel/ Cast Steel 2. Alloy Steel 3. Stainless Steel 4. Gray Pig Iron 5. nodular Cast Iron 6. Cast Aluminum 7. Brass 8. Bronze 9. Copper 10. Forging Steel 11. Rolling Steel

  • Statistics: Average/Max/Min/S Value
  • Memory: 999 Data
  • Operating Environment: -10°C~45°C
  • Power Supply: 2 x AA battery
  • Dimension: 145x68x28 mm
  • Weight: 158 g

Standard Delivery:

  • Main Unit: 1Pc
  • Wired Probe D: 1Pc
  • Hardness Test Block D:1Pc
  • Small Support Ring: 1Pc
  • Cleaning: 1Pc


  • Can use wired probes or wireless probes
  • Dual—coil probe for high accuracy
  • Universal testing angle, no need to set impact direction
  • Based on Leeb (HLD), converted to Vickers (HV), Brinell (HB), Rockwell (HRC, HRA and HRB), Shore (HS) and tensile strength (αb)
  • Dual value display, shows both Leeb and converted hardness
  • Large 2.4″ LCD display with backlight
  • With a magnet on the back, the main unit can be attached on steel surfaces
  • According to ASTM A956 and DIN 50156
