Semi-Automatic Kjeldahl Apparatus (Model No:- HV-504-KA)

Semi-Automatic Kjeldahl Apparatus (Model: HV-504-KA)

Þ Nitrogen Recovery99.8 - 100 %

Þ Accuracy Supersedes conventional Kjeldhal apparatus results.

Þ Reproducibility± 1% relative or better

Þ Analysis range0.5 - 160 mg of nitrogen / 3 - 1000 mg of protein

Þ Distillation Capacity3 - 4 minutes per sample (15 to 20 samples per hour)

Þ Receiver Solution *Programmable between 15-50ml

Þ Water dilution Programmable between 0-100 ml in steps of 10ml

Þ Alkali addition Automatic mode / Manual mode (Continuous)

Þ Alkali volume Programmable between 15 - 50 ml

Þ Reaction delay time Programmable 0-5 minutes.

Þ Distillation time Programmable 1-99 minutes

Þ Steam generator Borosilicate glass / Stainless Steel and Safety valve

Þ Temperature control RTD based Micro controller with Standby mode.

Þ Water level control Stainless Steel Float Switches

Þ Cooling Water Automatic (90 Liters per hour) Nil with CRC 25 Chiller*

Þ Condenser Made of borosilicate glass

Þ Distillate collection18 - 25 ml per minute optimally.

Þ Water/Alkali tank5 Liters ea.

Þ Dimension (W x D x H)370 x 320 x 720 mm.

Þ Electrical requirement230V, 50Hz Single phase AC, 1500W.

Internal Code: - KD.6012.220415
