Single Stage Quartz Distillation Horizontal (Model No. HV-SQD Series)
Single Stage Quartz Distillation Horizontal
- Replaceable Silica Heater: The Horizontal Quartz Jacket is fitted with removable silica heater and screw threaded connectors for ease of cleaning when scaling is formed.
- Distillate temperature is around 25 to 45°C which is ensured by an efficient condenser.
- The stand is powder coated for rust free operation and lustrous appearance.
- The unit automatically switches off if water level in the boiler falls below
- Cooling water from the condenser is re-circulated into the boiling chamber, hence saving energy.
- Electrical Power: 220/240 V, 50/60Hz, Single Phase Supply.
- Boiler is provided with Teflon Screw Cork for easy draining and cleaning of boiling chamber.
This model is equipped with in-built temperature switch to protect the Glass
Parts in case of water failure or overheating.
