Touch Screen Microprocessor Dissolution Test Apparatus (Eight Basket) (Model No. HVO-DTA-7210)

Touch Screen Microprocessor Dissolution Test Apparatus (Eight Basket) (Model No. HVO-DTA-7210)


  • Rs. 269,555.00

Touch Screen Microprocessor Dissolution Test Apparatus (Eight Basket)

Range 25-200 RPM, resolution 1 RPM 2,60,000 and accuracy ± 1 RPM, Snap-fit Paddle Attachment, Marble Finish Top Plate, Circulating Pump, 40 Setup Storage facility, 400 test samples storage and with printer attachment facility. Password protected data login facility. USB interface for computer connection available


Technical Specification

  • Stations: 8 Basket
  • Display: 7 Inches Colored Touch Screen
  • Prag. Mode: Routine, Sustain and Control mode. Facility for 20 different test setups available in Routine and Sustain mode.
  • Printer: Provision for the attachment of dot-matrix printer with Centronics parallel port interface available.
  • Stirrer Speed: 25 - 200 RPM, ± 1 RPM
  • Resolution: 1 RPM
  • Accuracy: +1 RPM
  • Temperature Range: 30°C to 50°C
  • Accuracy: ±1°C
  • Temp. Control: Microprocessor Based using PT100/Semiconductor Sensor
  • Reaction Vessel: 1000 ml jars with stirrer pedals and baskets
  • Heater: 1KW
  • Power: 230V ±10%, 50 Hz. AC

Standard Accessories:

  • Main Unit with Acrylic Tank and Rectangular Cover Plate and Water Bath Temperature Sensor (T1)
  • Heater Bath Circulating Pump
  • External Temperature Sensor (T2) for Vessel
  • Reaction Vessel capacity 1000 ml ((8 Nos.)
  • Round Acrylic Cover Plate with Hole and a large slit(8 Nos.) S.S. Paddle, S.S Wire Mesh Basket (8 Nos.)
  • Glass pipettes with rubber bellows Mains Lead
  • Instruction Manual
  • Dust Cover

Salient Features:

  • 7 Inches Colored Touch Screen
  • Password protected data login facility.
  • Complies with USP, IP specifications
  • Extremely Useful for Pharmaceutical Labs
  • Highly Accurate and Easy to Operate
  • Programmable Stirrer Speed Control i.e. (25 - 200 RPM)
  • USB Interface Available
  • Three Programming Modes i.e. Routine, Sustain and Control
  • 40 Independent Programmable Setups for Routine and Sustain Mode with               Storage Facility
  • 400 Samples Storage Facility
  • Printer Attachment Facility
  • Audio Visual Indicators for System Status
  • Easy to Empty & Clean the Water bath with Bottom Drainage
  • Continuation of Last Sample Run in case of Power Failure
