Digital Turbidity Meter (Model No. HV-TB200)

Digital Turbidity Meter

Specification:

• Measurement Range: 0~2000 NTU, 0~500 EBC, 0~9999 ASBC
• Resolution: 0.01 (0~100 NTU), 0.1 (100~999 NTU), 1 {999~2000 NTU)
• Accuracy:

±2% of reading for 0~500 NTU
±3% of reading for 501~2000NTU

• Calibration Points: 2 to 7 points (0.02, 10.00, 200,500, 1000, 1500, 2000 NTU)
• TSS Range: depending on the TSS conversion factor

• Resolution: 0.1/ 1
• TSS Accuracy: ±3% of reading
• Light Source – Infrared –emitting diode (850 nm wavelength)
• Detector: Silicon Photodiode
• Stray Light: <0.02 NTU
• Sample Vials: 60 (H) x 25 (Dia)mm
• Memory – Stores up to 200 data sets
• Display: 4.5” TFT display
• Password Protection: Yes
• Operating Temperature: 0~50°C
• Power Requirements: Adaptor, Using AC 220V,50/60Hz

Salient Features

• Turbidity meter with TSS measurement mode, selectable four turbidity units
• Turbidity meter is equipped with a 4.5" TFT display.
• 2 to 7 points calibration using the Formazin Standards.
• Selectable four turbidity units, including the NTU, FNU, EBC and ASBC.
• TSS conversion factor ensures accurate measurement for Total Suspended Solids.
• Continuous measurement mode that can used for indexing and matching the sample vials.
• Hold function freezes current reading for easy viewing and recording.
• Password protection prevents the unauthorized calibration and settings.
• Help message as a operational guide that helps user quickly begin using the meter.
• System menu allows setting the 9 parameters, including the date and time, resolution, etc.
• Reset feature automatically resumes all settings back to factory default settings.
