Product details
Ultrasonic Thickness Gauge
MODEL NO: HV-1401
Display mode: Four-digit LCD display.
Working frequency of the probe: 5MH, Range: 1.5~225mm (steel), Resolution ratio: 0.1mm, Measurement accuracy: ±(1%H+0.1) mm, H is the object thickness. Lower measurement limit of pipes: Φ20×3mm
Sound speed adjustment scope: 1000~9999m/s
Measuring sound speed with known thickness: Measurement scope:1000~9999m/s; When thickness of measured objects is ≤20mm, the precision of sound speed measurement is ±1mm/H*100%; when the object thickness is > 20mm, precision of sound speed measurement is±5%.
Power supply: 3 x 1.5V AA alkaline batteries
Working temperature: 0~40℃, Relative humidity: < 90%RH
Storage temperature: -10~50℃, Workpiece temperature: < 60℃, Working current: < 100Ma
Measurement accuracy: ±(1%H+0.1) mm, H is the object thickness.
Internal code: VA.6458.230206
