Autoclave Double Door (Model No: HV-1216)

Autoclave Double Door (Model No: HV-1216)


  • Rs. 414,700.00

Autoclave Double Door


These machines are horizontal type and feature two (DOUBLE) doors. These double door autoclave systems are medical grade and are designed for medical, pharmaceutical manufacturing and clean room applications. These units are manufactured with corrosion resistant stainless-steel construction.
  • Chamber Capacity 150 Liters
  • Operating pressure range MPa 0.02 to 0.22, Operating temperature range Up to 134°C
  • Power of electric heating tube KW 12, Relative humidity ≤80%
  • Uniformity ± 2.0°C at 121°C, Atmospheric pressure 86 to 106 kPa
  • Heat Up Time to 121°C Approx. 25min
  • Steam source pressure 0.30 to 0.60 MPa
  • Compressed air source pressure 0.30 to 0.60 MPa
  • Water source pressure 0.15 to 0.30 MPa
  • Control System Microprocessor Based
  • Construction 304 / 316 / 316L Stainless Steel
  • Heating Type Direct heating by immersed copper tubes of heating elements
  • Power Supply 220 / 240 Volts
  • Safety Device: Hydraulic Over Temperature Protection Safety Device, Electrical Leakage Breaker, Pressure: Mechanical Over pressure safety valve
  • Accessories: Direct electric heating OR LPG operated steam generators, Rapid water re-cooling, Vacuum pump, Low water protection device, Timer w/ alarm system, Digital temperature indicator, Printer & Digital chart recorder & PLC control system, Cycle with pre-vacuum option, Stainless Steel flush mounting, Carriages, Trolleys, Trays, and Baskets, Sterilization indicator

Product Internal Code: 8615
