3D Tester (Model No. HVO-2840-3D)
3D Tester
Specifications:
- Range: ±1.0mm
- Graduate: 0.01mm
- Repeatability: ±0.01mm
- X, Y, Z Range: 6mm
Features
- Shockproof, IP67 dust/waterproof
- Mainly used for milling machines and CNC machine tools
1. determine coordinate point on workpieces
2. find center of holes
3. adjust and position workpieces
- Can be used to measure length and depth
- When using standard probe, reading shows movement value of probe, for example, if probe moves 0.05mm, reading changes 0.05mm (5 graduations). When using extended probe, reading does not show movement value of probe
- Large working range on three axes (X, Y, Z), which avoids damage of probes due to collision by mistake
Probe Optional:
1. Standard Probe
- L: 36mm
- D: SØ4mm
2. Extended Probe
- L: 56.6mm
- D: SØ6mm
