Atomic Absorption Spectrophotometer (Single Beam) (Model: HV-2100)
Atomic Absorption Spectrophotometer (Single Beam)
(Model: HV-2100)
Technical Specifications:
- Parameter: Computer controlled, High performance, optically single beam Atomic Absorption Spectrometer having following specifications.
- Optics: Real time Single beam with Deuterium background
- Monochromator: CZ design with 330 mm focal length, 1800 line/mm grating and 185-930 nm wavelength range. Automatic emission wavelength selection and peaking. Continuously variable slits with 0.2 to 2 nm spectral bandwidth. Automatic wavelength scanning. Selected wide range
- Detector: High performance multi-alkali Photo multiplier tube R928
Motorized Lamp Turret: 8 lamp motorized turret with automatic lamp selection and individual lamp peaking automatically warmed up. Compatible with standard & coded hollow cathode lamps
- Flame Control Unit: Manual flame control fully safe & sturdy having independent flow meter
- Nebulizer: Fully inert nebulizer
- Spray Chamber: PTFE spray chamber and adjustable impact bead aerosol.
- Burner: Titanium burners for C, H, -N,O & C2H2 - AIR
- Sensitivity: Greater than 0. 7 abs for 5 mg/L copper solution with an RSD of less than 0.5% Characteristics concentration of copper 0.030 ug/ml
- Output Port: RS 232 / USB
- Software: Windows 10 based user-friendly software
- Dimension: 100 x 55 x 58 cm (L x H x W) cm
- Weight: 65 kg, Unpacked.
- Electrical Requirements: 220/240 V AC, 50/60 Hz, 800 VA
Hollow cathode Lamp: 67 Element high intensity Single Element available
Internal Code: - KD. 2802-R.251209
