BENCHTOP IVF TRIGAS INCUBATOR (MODEL NO. HVO-HCC-160 LTR)

BENCHTOP IVF TRIGAS INCUBATOR

(MODEL NO. HVO-HCC-160 LTR)

TECHNICAL SPECIFICATIONS: -

• Benchtop Trigas incubator for oocyte culture, in-vitro fertilization and embryo culture

• Volume: 160L

• Display: LED touch screen display

• Temperature control: Range [°C]: Ambient +5°C ~50°C. Accuracy [°C]: ±0.1 (37°C)

Resolution [°C]: 0.1

• Control: Digital PID

• CO2 range: (0~20) % V/V Accuracy of ± 0.1 % (5%/37°C) Resolution: 0.1%

• O2 range: 0.6-85% Accuracy: 0.1% Sensor: Zirconium dioxide sensor

• N2 range: 5~90% Accuracy: ± 0.1%

• Jacket type: dry wall and air jacket system.

• HEPA filtration along with a 90°C moist heat disinfection system for a contamination free growing environment for cells.

• Hot air sterilization: Maximum 125°C Dry Hot Air

• Chamber material: stainless steel

• Shelves (pcs): 4

• Humidity Method: natural humidification using water tray

• Perforated Shelves: perforated shelves are good for natural air flows.

• Direct heating system: The electric heating wire is covered on all sides of the chamber

which makes good uniformity and provides fast heat-up & temperature recovery. 3

parts of heating section are controlled and calibrated individually by 3 individuals

temperature sensors.

• Provide one CO2 cylinder and one N2 cylinder.

• Provide 2 Gas regulators (one each for 31 kg CO2 and N2 cylinders) 5–6-meter non permeable suitable tubing to connect the cylinder with incubator, cylinder stands to hold the cylinder.

• provide power socket

INTERNAL CODE: - KD.25613
