Binocular Research Microscope (MODEL NO. HVS-BRM-107)

Binocular Research Microscope

(MODEL NO. HVS-BRM-107)

Technical Specification: -

1. Siedentop observation Trinocular head inclined at 30° rotatable at 360°. Diopter adjustment ring on ocular tube and inter pupillary distance from 50 mm to 75mm. Vertical, Focusable for digital camera

2. Microscope have Anti fungus coated wide filed 10x paired FOV 18mm or higher eyepiece.

3. Three-position sliding rod directs light 100% to binocular eyepieces, or 100% to camera, or 70% to camera and 30% to eyepieces. Microscope has a 1.25 N.A. bright field.

4. Abbe condenser with rack-and-pinion focusing, iris diaphragm, and swing-out filter with blue, green, and yellow filters.

5. Double plate mechanical stage size 140mm X 155mm having low positioned co axial controls on ball bearing and cross movement 55mm X 75mm, slow motion has 1div= 0.002mm.

6. Co axial focusing system. PRE focusing lever and tension adjustment ring.

7. Magnification of 40x/100x/400x/1000x available.

8. Head Configuration Binocular.

9. Objectives Anti fungus coated Semi Plan objective 4x/10x/40x SU100x oil SL;

10. Built in base illumination system with 3W LED bulb and adjustable brightness.

11. Abbe condenser NA 1.25 swing out filter holder. iris diaphragm

12. System come with Operating manual, Dust cover, cord and plug.

13. System have digital LCD with given specification.

. 9" screen, high resolution (1024 x 768) colour LCD.

. Built- in Camera with 5.0 Megapixel resolutions.

. Pre-loaded capture & measurement software.

. LCD screen can be rotated at 360, 90 vertically.

. OS: Android 4.1.1

. CPU: Dual core 1.5 GHz, 1G (DDR3) Memory, Internal 5 GB

or external Mini SD card HDMI display.

. Output ports: one HDMI, one USB2.0, one Mini USB

INTERNAL CODE: - KD.25610
