BOD INCUBATOR (MODEL NO. HVO-BOD-152)

BOD INCUBATOR

(MODEL NO. HVO-BOD-152)

Designed for low temperature incubation and routine determination of Bio-chemical oxygen demand (B.O.D.). For work in lower temperature a cooling unit is provided at the lower portion of the working chamber and heating arrangement has been made in the inner chamber for work of higher temperature. Air circulation fan provided to keep the temperature uniform inside the chamber. Double wall door is provided with magnetic gasket and lock & key arrangement. Inner door made out of Plexi glass door allowing inspection of material in the chamber without disturbing the chamber temperature. Door operated inner illumination has been provided. Incubator to work on 220 V AC 50 Hz single phase

Technical Specification: -

• Capacity: 220 lts

• Temp. Range: 2°C – 60°C

• Temperature accuracy: ±0.5 ͦC

• Temperature uniformity: ±1 ͦC

• Construction: Double wall

• Insulation: Thick PUF insulation

• Compressor: Hermetically sealed Compressor CFC Free.

• Display: Touch screen display

• Temperature control: Combined Imported PID Controller.

• Humidity System: Yes

• Sensor: High quality temp. sensor.

• Blower: Motorized Blower is fitted inside the chamber to maintain the uniform temperature.

• Safety device: Low and high temp. cut off settable thermostat.

• Heater: U Shaped Tubular heater

• Inner Chamber: 304 (1mm) quality Stainless Steel.

• Outer Chamber: Outer body with heavy GI sheet (1.25mm) and powder quoting paint finish.

• Door: 1 no full Plexi glass door and 1 no solid door with gasket and lock.

• Timer: 0- 24 hours.

• Alarm and: Hi – Low temp. alarm

• Number Of Selves: 6 Nos. of removable & Adjustable SS wire mesh selves.

• Wheels: Yes

INTERNAL CODE: - KD.25610
