CO2 Incubator (Model: HVS-C170)


  • Rs. 410,000.00

'HOVERLABS’ Carbon Dioxide (CO2) Incubators provide optimal growing conditions and contamination prevention for valuable cell cultures. We provide a wide range of CO2 incubators, ranging from a small capacity and volume to a large scale capacity cabinet. All the CO2 incubators are built with the patented Water Jacket and Air Jacket systems, which minimizes the risk of condensation at the present and in the future.
Type of Incubator
 Double Walled, Convection Heated Unit with Microcomputer Controller, Indicator and interior light.
Application: Immunology, Oncology Genetics & and Bio Engineering. Widely applicable for research and production of Microorganisms, Agricultural Science and Pharmacology.
Temperature Range: RT 3°C to 60°C with an accuracy of ± 0.3°C
Relative Humidity: >90% at 37⁰
Time Setting: 999h or continuous.
Alarm & Password Protection: Audible and Visual Alarm; Over-Temperature Alarm; CO2 Concentration Alarm, Password Protected Thermal Decontamination Process
CO2 Range: Infrared Sensor, Range 0~20%
CO2 Control Resolution: 0.10%
Number of Shelves: 03 or more Perforated S.S. Shelves with Adjustable Height
Heating: Air Jacket
Humidification Type: Water tank for Natural Evaporation
Sterilization Type: UV lamp for Air Jacket
Dimensions (Apprx.) (W x D x H) mm
Internal: 550 x 500 x 800, External: 800 x 600 x 1300, Packing Size: 800 x 900 x 1500
Weight: 150Kgs. (Apprx.)
Power Supply & Consumption: AC110/220V ±10%, 50/60Hz, 1000 W
Accessories Including: Supplied with the High-Pressure CO2 Cylinder, 2 Units of CO2 Regulators, 2KVA Online UPS to provide 30 minutes backup, Adapter & Working Operation Manual.
Construction Features
§Inner chamber is made up of Stainless Steel (SS 304 grade) sheet with round corners.
§Exterior fabricated out of Cold Rolled Steel with painting.
§CO2 Incubator with a size of 170L (6 cu ft) and capacity to hold 03 standard S.S shelves and a maximum capacity of 10 or more shelves.
§Equipped with 03 removable perforated S.S. shelves with adjustable height.
§It Includes Inner & Outer Door. Inner door made out of clear acrylic sheet allowing inspection of material in the chamber without disturbing the chamber temperature.
§Electropolished Stainless Steel 304 - grade chamber adopts round angle structure, easy to clean.
§Equipped with Interactive navigator touchscreen for trend analysis for convenient evaluation of unit's performance, featuring door-mounted position for easy access with multiple language selection, ease of View instructions, monitor progress, on-screen menu prompts, error and usage logs, data logging, performance trend graphing, decontamination routine, and running log of all user interactions with the incubator. The system shows graph performance trends over established timeframes and run event history logs - protected with user passcodes and control lockouts.
§The system is equipped with an independent high quality thermal protection and fan assisted circulation to protect the samples from harmful overheating in case of failures. The direct air jacketed heating design provides stable temperature control, uniformity and rapid recovery of all parameters (temperature, CO2, and relative humidity) following a door opening.
§Active Airflow Technology is designed to provide uniformity & fast recovery of all parameters in 10 minutes or less following a routine door opening. ‘In-chamber Fan’ gently distributes clean, humidified air throughout the chamber ensuring homogeneous conditions.
§CO2 concentration range is 0-20 % with CO2 sensor technology IR sensor withstand 180-190°C decontamination cycle run & situated inside the chamber & need not to be remove during heat decontamination.
§Temperature range ambient +3 to 60⁰ with maximum deviation spatial ± 0.3 and control of ±0.1°C.
§The Microprocessor Control PID based system with over temperature protection gives clear cut written message for the errors, guides through the cycle with start-up and cycle status messages during decontamination phase.
§The system shows graph performance trends over established timeframes and run event history logs - protected with user passcodes and control lockouts.
§Possibility of automatically calibrating all electronic measurement and control functions.
§For humidity 2-3 Liters water reservoir that provides a high relative humidity (rH) with a water level sensor which indicates when a refill is needed.
§Floor heating system which directs heat transfer from heated floor to humidity reservoir.
§Heat decontamination- at 180°C. Heat decontamination for more than 12 Hrs time cycle & with 12 Log sterility assurance level. No chemical is used for decontamination.
§The decontamination process does not require the disassembly and removal of sensors, hardware or other components for separate autoclaving.
§Data output of the event log through USB.
§HEPA filtration provides continual protection against airborne contaminates by filtering the entire volume of air inside the incubator every 60 seconds to achieve cleanroom-quality ISO Class 5 (Class 100) air in 5 minutes following a 30-second door opening.
§High quality Microbiological CO2 gas filter ensures the inside gas quality.
§40 mm (1.5 in) access port which allows cables, plugs, and tubing to be easily inserted into or out of the chamber.
Salient Features
1. Water tank for humidity in the chamber.
2. Air Jacket: Equipped with UV Lamp for sterilizing.
3. Water jacket: equipped with HEPA filter which ensures that Class 100 air quality is achieved within five minutes of the door closing.
4. Equipped with USB port and LCD touch screen, the incubator can save data in real time.
5. High quality CO2 gas filter ensures the inside gas quality.
6. SMC brand gas circuit valves ensure more stable CO2 concentration and less consumption of CO2 gas.
7. Microcomputer controller, LCD displays temperature, CO2 concentration, run-time and timing.
8. High quality infrared sensor for accurate CO2 concentration.
9. Mounted on 4 Footmaster Castors for easy movement.
10. The working chamber adopts round angle structure, easy to clean.
Certification: ISO, CE, WHO-GMP, US FDA Certified
