CO2 Incubator (Model: HVS-C170A)
Type of Incubator
Double Walled, Convection Heated Unit with Microcomputer Controller, Indicator and interior light.
Application: Immunology, Oncology Genetics & and Bio Engineering. Widely applicable for research and production of Microorganisms, Agricultural Science and Pharmacology.
Temperature Range: RT 5°C to 60°C with a accuracy of ± 0.5°C
Ambient Temp. & Humidity: 18 ~ 30, suggest 25 ±2 °C; relative humidity <80%
Time Setting: 999h or continuous.
Alarm & Password Protection: Audible and Visual Alarm; Over-Temperature Alarm; CO2 Concentration Alarm, Password Protected Thermal Decontamination Process
CO2 Range: Infrared Sensor, Range 0~20%
CO2 Control Resolution: 0.10%
Number of Shelves: 4 Perforated S.S. Shelves with Adjustable Height
Heating: Air Jacket
Humidification Type: Water tank for Natural Evaporation
Sterilization Type: UV lamp for Air Jacket
Dimensions (Apprx.) (W x D x H) mm
Internal: 550 x 500 x 800, External: 800 x 600 x 1300, Packing Size: 800 x 900 x 1500
Weight: 150Kgs. (Apprx.)
Power Supply & Consumption: AC110/220V ±10%, 50/60Hz, 1000 W
Accessories Including: Supplied with the 3KVA Voltage Stabilizer with auto cut-off reset, Delay Timer & Spike Eliminator, High Pressure CO2 Cylinder (18Kg), CO2 Regulator, Adapter for proper functioning of the equipment.
Double Walled, Convection Heated Unit with Microcomputer Controller, Indicator and interior light.
Application: Immunology, Oncology Genetics & and Bio Engineering. Widely applicable for research and production of Microorganisms, Agricultural Science and Pharmacology.
Temperature Range: RT 5°C to 60°C with a accuracy of ± 0.5°C
Ambient Temp. & Humidity: 18 ~ 30, suggest 25 ±2 °C; relative humidity <80%
Time Setting: 999h or continuous.
Alarm & Password Protection: Audible and Visual Alarm; Over-Temperature Alarm; CO2 Concentration Alarm, Password Protected Thermal Decontamination Process
CO2 Range: Infrared Sensor, Range 0~20%
CO2 Control Resolution: 0.10%
Number of Shelves: 4 Perforated S.S. Shelves with Adjustable Height
Heating: Air Jacket
Humidification Type: Water tank for Natural Evaporation
Sterilization Type: UV lamp for Air Jacket
Dimensions (Apprx.) (W x D x H) mm
Internal: 550 x 500 x 800, External: 800 x 600 x 1300, Packing Size: 800 x 900 x 1500
Weight: 150Kgs. (Apprx.)
Power Supply & Consumption: AC110/220V ±10%, 50/60Hz, 1000 W
Accessories Including: Supplied with the 3KVA Voltage Stabilizer with auto cut-off reset, Delay Timer & Spike Eliminator, High Pressure CO2 Cylinder (18Kg), CO2 Regulator, Adapter for proper functioning of the equipment.
Construction Features
1. Inner chamber is made up of Stainless Steel (SS 304 grade) sheet with round corners.
2. Exterior fabricated out of Cold Rolled Steel with painting.
3. CO2 incubator with a size of 170L (6 cu ft) and capacity to hold 4 standard S.S shelves and a maximum capacity of 10 or more shelves.
4. Equipped with 4 removable perforated S.S. shelves with adjustable height.
5. Interactive navigator touchscreen for trend analysis for convenient evaluation of unit's performance, View instructions, monitor progress, decontamination routine, and running log of all user interactions with the incubator.
6. It Includes Inner & Outer Door. Inner door made out of clear acrylic sheet allowing inspection of material in the chamber without disturbing the chamber temperature.
7. The system shows graph performance trends over established timeframes and run event history logs - protected with user passcodes and control lockouts.
8. The system is equipped with an independent thermal protection to protects the samples from harmful overheating in case of failures.
9. Data output of the event log through USB.
10. The Microprocessor Control PID based system with over temperature protection gives clear cut written message for the errors, guides through the cycle with start-up and cycle status messages during decontamination phase.
11. Possibility of automatically calibrating all electronic measurement and control functions.
12. For humidity 3 Liters water reservoir that provides a high relative humidity (rH) with a water level sensor which indicates when a refill is needed.
13. Floor heating system which directs heat transfer from heated floor to humidity reservoir.
14. Heat decontamination at 90°C. Heat decontamination for more than 9 Hrs time cycle & no chemical is used for decontamination.
15. The decontamination process does not require the disassembly and removal of sensors, hardware or other components for separate autoclaving.
16. 40 mm (1.5 in) access port which allows cables, plugs, and tubing to be easily inserted into or out of the chamber.
3. CO2 incubator with a size of 170L (6 cu ft) and capacity to hold 4 standard S.S shelves and a maximum capacity of 10 or more shelves.
4. Equipped with 4 removable perforated S.S. shelves with adjustable height.
5. Interactive navigator touchscreen for trend analysis for convenient evaluation of unit's performance, View instructions, monitor progress, decontamination routine, and running log of all user interactions with the incubator.
6. It Includes Inner & Outer Door. Inner door made out of clear acrylic sheet allowing inspection of material in the chamber without disturbing the chamber temperature.
7. The system shows graph performance trends over established timeframes and run event history logs - protected with user passcodes and control lockouts.
8. The system is equipped with an independent thermal protection to protects the samples from harmful overheating in case of failures.
9. Data output of the event log through USB.
10. The Microprocessor Control PID based system with over temperature protection gives clear cut written message for the errors, guides through the cycle with start-up and cycle status messages during decontamination phase.
11. Possibility of automatically calibrating all electronic measurement and control functions.
12. For humidity 3 Liters water reservoir that provides a high relative humidity (rH) with a water level sensor which indicates when a refill is needed.
13. Floor heating system which directs heat transfer from heated floor to humidity reservoir.
14. Heat decontamination at 90°C. Heat decontamination for more than 9 Hrs time cycle & no chemical is used for decontamination.
15. The decontamination process does not require the disassembly and removal of sensors, hardware or other components for separate autoclaving.
16. 40 mm (1.5 in) access port which allows cables, plugs, and tubing to be easily inserted into or out of the chamber.
Salient Features
1. Water tank for humidity in the chamber.
2. Air Jacket: Equipped with UV Lamp for sterilizing.
3. Water jacket: equipped with HEPA filter which ensures that Class 100 air quality is achieved within five minutes of the door closing.
4. Equipped with USB port and LCD touch screen, the incubator can save data in real time.
5. High quality CO2 gas filter ensures the inside gas quality.
6. SMC brand gas circuit valves ensure more stable CO2 concentration and less consumption of CO2 gas.
7. Microcomputer controller, LCD displays temperature, CO2 concentration, run-time and timing.
8. High quality infrared sensor for accurate CO2 concentration.
9. Mounted on 4 Footmaster Castors for easy movement.
10. The working chamber adopts round angle structure, easy to clean.
Certification: ISO, CE, WHO-GMP, US FDA Certified
3. Water jacket: equipped with HEPA filter which ensures that Class 100 air quality is achieved within five minutes of the door closing.
4. Equipped with USB port and LCD touch screen, the incubator can save data in real time.
5. High quality CO2 gas filter ensures the inside gas quality.
6. SMC brand gas circuit valves ensure more stable CO2 concentration and less consumption of CO2 gas.
7. Microcomputer controller, LCD displays temperature, CO2 concentration, run-time and timing.
8. High quality infrared sensor for accurate CO2 concentration.
9. Mounted on 4 Footmaster Castors for easy movement.
10. The working chamber adopts round angle structure, easy to clean.
Certification: ISO, CE, WHO-GMP, US FDA Certified
