Product details
Coating Thickness Gage (High Precision)
•Probe: Magnetic induction probe (included)
•Measuring Range: 0-500μm
•Resolution: 0.1μm (range<100μm); 1μm (100μm≤range≤500μm)
•Accuracy: ±(0.5+2%L) μm L is measuring thickness in µm
•Repeatability: ≤(0.2+0.8%L) μm L is measuring thickness in µm
•Measuring mode: Single and Continuous
•Measure interval: Single mode: 1.5s, Continuous mode: 0.4s
•Calibration mode: zero calibration and multi-points calibration (1-5 points)
•Minimum substrate thickness: 0.1m
•Minimum measuring area: 7mm
•Minimum radius of curvature workpieces: Convex surface: 1.5mm, Concave surface: 10mm
•Unit: µm/mil
•Power supply: 4x1.5V AAA batteries
•Dimension: 148x76x26mm
Internal code: VA.9002.240403
