Contact/Non-Contact Tachometer (Model No. HVO-9225-405)
Contact/Non-Contact Tachometer
Specification:
- Measuring method: Non-contact/ Contact
- Measuring Range:
Rotary Speed:
2.5~99999 RPM (Non-Contact)
0.5~19999 RPM (Contact)
Line Speed:
0.05~500m/min (Contact)
- Resolution:
Rotary Speed (Non-Contact):
0.1 RPM (range 2.5-999.9RPM)
1RPM (range 1000-99999RPM
Rotary Speed (Contact):
0.1 RPM (range 0.5~999.9 RPM)
1 RPM (range 1000~19999 RPM)
Line Speed (Contact):
0.01 m/min (range 0.05~99.99 m/min)
0.1 m/min (range 100~500 m/min)
- Accuracy:
Rotary Speed (Non-Contact):
±(0.05%n+1d) RPM
'n' is rotary speed, 'd' is resolution
Rotary Speed (Contact):
±(0.4%n+1d) RPM (n<300RPM)
±(0.05%n+1d) RPM (n>300RPM)
n is rotary speed, d is resolution
Line Speed (Contact):
± (1%+1d) m/min d is resolution
- Laser Power (Non-Contact): Class 3R, 3mW~4mW
- Sampling Time: 0.6s (above 100 RPM)
- Measuring Distance (Non-Contact): 50~500mm
- Operation Temperature: 0~40°C
- Power Supply: 3xAA batteries
- Dimension: 260x71x36mm
- Weight: 170g
Features:
- 2 measuring method, contact and non-contact
- Can measure rotary speed and line speed
- Automatically save the maximum value, minimum value and the last value, 500 data can be stored during continuous measurement
- Automatic power off
Standard Delivery:
- Main Unit: 1Pc
- Reflection Sticker: 3Pcs
- Wheel with 0.1m Perimeter: 1Pc
- Clamping Sleeve: 1Pc
- Cone Head: 1Pc
- Small Cone Head: 1Pc
- Cone Cavity Head: 1Pc
- Battery (AA): 3Pcs
