DIGITAL CLINICAL FLAME PHOTOMETER
| Dual channel single aspiration with filter (Na & k) for medical use. Final result in meq/L 2½ digit dual LED display for simultaneous results along with compressor & accessories . * Model : LT-66(Digital Clinical Flame Photometer) * No. of Filters : Na & K (Ca & Li optional) * Range : Na: 0-200 meq/l Ca: 0-2 meq/l ', K : 0-100 meq/l, Li: 0-10 meq/l * Sensitivity : Na: 5 pmm Ca: 10 ppm , K : 5 pmm Li: 10 ppm * Display : Dual 2 1/2 digit bright LED Display * Accuracy : + 2% upto 100 meq/l , + 5% above 100 meq/l * Repeatability : + 2 Count * Detector : Silicon Photodiode * Filters : Narrow band interference glass filters * Nebulizer : Black bakelite, axial flow type * Flame System : LPG and dry oil free air * Warmup time : 10 minutes * Power : 230V + 10% AC 50 Hz * Size (LxBxH) : 455 x 250 x 210 mm * Weight : 7.5 kg (Approx.) Air Supply : By Oil free mini compressor unit with pressure regular Combustion : LPG controlled by precision regulator Power : 230V +10% AC 50 Hz Size (LxBxH) : 275 x 192 x 240 mm Weight : 9 Kg (Approx.) Accessories : Instrument with Na & K Filters, Instruction Manual, Dustcover, Chimney, Air Tubing |
