Digital Disc Tube Rotator with Microprocessor & Brushless Motor (Model No. HVO-DR24)
Digital Disk Tube Rotator with Microprocessor & Brushless Motor
- Brushless DC motor for quiet operation and maintenance free long life operation
- Microprocessor controlled disc rotator with variable speed and time setting, along with last run memory function
- 10 to 80 RPM Adjustable speed range with increment and +/-1 accuracy
- 1 to 99 minutes timer setting and infinite mode
- User programmable - save up to 9 user defined programs {protocols)
- Pulse mode with alternate clockwise and anticlockwise motion with 2 second intervals for better and thorough mixing
- 0 to 90 degrees adjustable angle
- Automatic Power On in case of power interruption, instrument completes run on remaining duration after power resumption
- Easy removal/ installation of Disc plates for replacement & cleaning
- CE Certified
Technical Specification:
- Programmable Mode: Set and save up to 9 users defined programs
- Variable Speed: 10-80 RPM
- Motor Type: Brushless DC motor
- Pulse Mode: Alternate clockwise and anticlockwise motion with 2 second intervals
- Run Time: 1 to 99 mins & Infinite mode
- Angle of Disc Plate: Adjustable from 0-90 degrees
- Weight: 3.9 Kgs
- Dimension (L x W x H): 383 x 325 x 325 mm
- Protection Class: IP 21
- Voltage/ Consumption: 24V :-:-: 0.2A / 4.5W
