DIGITAL FLAME PHOTOMETER
| With fitted (Na & K) 3½ digit LED display (ppm) along with compressor and other accessories Ca & Li filter can be provided on request. * Model : LT-65(Digital Flame Photometer) * No. of Filters : Na & K (Ca & Li optional) * Range : Na: 0-100 ppm Ca: 20-100 ppm, K : 0-100 ppm, Li: 10-100 ppm * Sensitivity : Na: 5 ppm Ca: 10 ppm, K : 5 ppm Li: 10 ppm * Display : 2 1/2 digit bright LED Display * Accuracy : + 2% upto 40 ppm , + 5% above 40 ppm * Repeatability : + 2 Count * Detector : Silicon Photodiode * Filters : Narrow band interference glass filters * Nebulizer : Black bakelite, axial flow type * Flame System : LPG and dry oil free air * Warmup time : 10 minutes * Power : 230V + 10% AC 50 Hz * Size (LxBxH) : 355 x 250 x 210 mm * Weight : 6.5 kg (Approx.) Air Supply : By Oil free mini compressor unit with pressure regular Combustion : LPG controlled by precision regulator Power : 230V +10% AC 50 Hz Size (LxBxH) : 275 x 192 x 240 mm Weight : 9 Kg (Approx.) Accessories : Instrument with Na & K Filters, Instruction Manual, Dustcover, Chimney, Air Tubing |
