Digital Measuring Microscope (Model No. HVO-ISM-PM200SA)
Digital Measuring Microscope
Specification:
- Magnification: 41X~200X
- Stand: Standard
- Pixel: 2M (Resolution: 166x200)
- Illumination: built-in adjustable LED
- Power Supply: USB 2.0 Cable (Voltage Required: 5±0.1V)
Magnification, Focus Distance, View Filed and Accuracy
| Magnification | Focus Distance | View Field (mm) | Accuracy |
| 50X | 21mm | 8.1x6.4mm | 30µm |
| 100X | 13mm | 3.9x3.1mm | 15µm |
| 150X | 16mm | 2.6x2.1mm | 10µm |
| 200X | 19mm | 1.8x1.5mm | 8µm |
Features
- Can take pictures and videos
- Supplied with software
- Calibartion rules (graduation 0.1 and 1mm are included
- With Focus Support
