Product details
Digital Measuring Microscope (with Display, Basic Type)
Specification:
- Magnification: 12.5X~80X
- Sensor: 1/2.8" CMOS
- Pixel: 2M
- Resolution: 1920x1080
- Frame Rate: HDMI: 60fps
- Measuring Accuracy: ±0.02mm
- Lies: Cross Lines, Scales Lines (number, colors and position of lines are adjustable)
- Output: HDMI
- Power Supply: Power Adapter
- Dimension: 380x260x350mm
- Weight: 4.5kg
Magnification and View Filed
| Auxiliary Objective | Specification | Camera Adapter |
| 0.5X (Included) | ||
| 0.5X (Optional) |
Magnification | 6.2~40X |
| View filed | 47x26~7.4x4mm | |
| 1X (Optional) |
Magnification | 12.5~50X |
| View filed | 23.5x13~3.7x2mm | |
| 2X (Optional) |
Magnification | 25-160X |
| View filed | 11.8x6.5~1.8x1mm |
Features
- 1080P high-definition image
- Built-in software without computer, operated by mouse
- Take pictures, save to USB flash disk
- Measurement results can be sent to Excel
- Brightness, contrast ratio, gain are adjustable
STANDARD DELIVERY
- Main Unit: 1Pc
- 0.5 Camera Adapter: 1Pc
- 1X Auxiliary Objective: 1Pc
- White/Black Plate: 1Pc
- Glass Calibration Rute: 1Pc
- 16GB USB flask disk: 1Pc
- Mouse: 1Pc
- HDMI-Cable: 1Pc
- Power Adapter- 3Pcs
