Digital Measuring Microscope (with Display) (Model No. HVO-ISM-DL301)

Digital Measuring Microscope (with Display) (Model No. HVO-ISM-DL301)

HOVERLABS

  • Rs. 226,464.00
8


Digital Measuring Microscope (with Display)

Specification:

  • Magnification: 15X~100X
  • Sensor: 1/2" CMOS
  • Pixel: 2M
  • Resolution: 1920x1080
  • Frame Rate: HDMI: 60fps
  • Output: HDMI
  • Power Supply: Power Adapter
  • Dimension: 570x300x430mm
  • Weight: 6.5kg

Magnification, Focus Distance and View Filed

Auxiliary Objective Specification Camera Adapter
0.5X (Included) 1X (Included)
1X
(Included)
Magnification 15~100X 30~200X
Focus Distance 70±2mm 70±2mm
View Field 16x11~2.5x1.6mm 7.8x5.3~1.2x0.8mm
2X
(Optional)
Magnification 30~200X 60~400X
Focus Distance 29±2mm 29±2mm
View Field 7.8x5.3~1.2x0.8mm
3.8x2.7~0.6x0.4mm


Magnification and Measuring Accuracy

Objective
Magnification
Magnification
Measuring
Accuracy
0.75X 15X ±8µm
1X 20X ±7µm
1.5X 30X ±6µm
2X
40X ±6µm
2.5X 50X ±6µm
3X 60X ±5µm
3.5X 70X ±5µm
4X 80X ±4µm
4.5X 90X ±4µm
5X 100X ±4µm


Features

  • 1080P high-definition image
  • Built-in software without computer, operation by mouse
  • Take pictures, save to USB flash disk
  • Measurement results can be output to Excel
  • Automatic white balance and exposure
  • Brightness, contrast ratio, gain are adjustable

STANDARD DELIVERY

  • Main Unit: 1Pc
  • 0.5 Camera Adapter: 1Pc
  • 1X Auxiliary Objective: 1Pc
  • Calibration Plate: 1Pc
  • 16GB USB flask disk: 1Pc
  • White/Black Plate: 1pc
  • Mouse: 1Pc
  • HDMI-Cable: 1Pc
  • Power Adapter- 3Pcs
