DIGITAL SPECTROPHOTOMETER (MODEL NO. HVS-DS91)

DIGITAL SPECTROPHOTOMETER

(MODEL NO. HVS-DS91)

PRODUCT FEATURES: -

✓ Range 340 to 960 nm

✓ Dual Digital Display for Wa¼velength & Data

✓ Wavelength Resolution 1 nm

✓ Highly Stable & Accurate

✓ Direct Concentration Facility

 ✓10mm,50mm &100mm path length

ACCESSORIES: -

✓ Cuvettes (10mm): 2 Nos.

✓ Cuvettes (10 mm & 50 mm): 2 Nos.

✓ Dust Cover: 1 No.

✓ Operation Manual

Technical Specification: -

• Range- 340 to 960nm

• Resolution- 0.1% T, Abs: 0.001, Conc.: 1

• Output- % T: 0 to 100%, Abs: 0 to 1.999, Conc.: 0 to 1999

• Detector- Silicon Photodiode

• Light source- 6 V, 10 W, Tungsten Halogen Lamp

• Monochromator - 600 lines/mm holographic grating

• Sample holder- 10 mm, 50 mm & 100mm path length

10 mm Cuvette holder

10 mm & 50 mm Cuvette holder

• Spectral bandwidth- 5 nm

• Wavelength resolution- 1 nm

• Wavelength accuracy- ± 2.5 nm

• Repeatability- ± 2 nm

• Display- 3½ Digit Bright Red LED Dual Display for Data & Wavelength

• Operating temp range- 5°C to 45°C

• Power - 230 V±10% AC, 50 Hz

• Dimensions (LXBXH)- 475 x 285 x 130 mm (Approx.)

• WEIGHT- 8.5 Kg. (Approx.)

INTERNAL CODE: - KD.25612
