Double Beam Microprocessor UV-VIS Spectrophotometer (Model: HVO-2202)

Double Beam Microprocessor UV-VIS Spectrophotometer

(Model: HVO-2202)

Technical Specification: -

- Function: Basic, Wavelength Scan, Multi Wavelength, Kinetics, Quantitative, DNN Protein.

- Wavelength Range: 190 -1100 nm

- Spectral Bandwidth: 1.0 nm

- Optical System: Double Beam, Grating 1200 lines/mm

- Wavelength Accuracy: ± 0.1 nm

- Wavelength Repeatability: ± 0.1 nm

- Scanning Speed: HI, MED & LOW, MAX. 3600 nm/min

- Photometric Accuracy: ±0.3 %T or ± 0.002 A/h @1A

- Photometric Range:     %T      : 0-200%

                                                 Abs    : -0.3 to 3A

                                                Conc.  : 0-9999 C

- Stray Light: < 0.03 %T@ 220 nm & 360 nm

- Stability: ± 0.001 A/h @ 500 nm

- Display: 7 Inches TFT Colour Screen

- Baseline Flatness: ± 0.001A/h (200 - 1000 nm)

- Sample Compartment: 8 cells with automatic cell changer - 10 mm path- length.

- Light Source: Halogen & Deuterium Lamps (Pre-Aligned)

- Output Ports: USB DRIVE, USB HOST & RS232

- Power: 230 V ± 10% AC, 50 Hz

- Dimensions (L x B x H): Instrument: 810 x 660 x 390 mm (Approx.)

Standard Accessories: -

- Quartz Cuvettes - A Set of 2

- Glass Cuvettes - A Set of 4

- Instruction Manual

- Software Manual

- Software CD

- USB Data Cable for PC Connectivity

- Mains Lead

- Dust Cover

Internal Code: - KD.2935.260117
