DOUBLE BEAM UV-VIS SPECTROPHOTOMETER (Model: HVS-TDS15A

DOUBLE BEAM UV-VIS SPECTROPHOTOMETER

Model: HVS-TDS15A

TECHNICAL SPECIFICATIONS: -

Function - Basic, Wavelength Scan, Multi Wavelength. Kinetics, Quantitative, DNA/Protein

Wavelength Range - 190 -1100 nm

Spectral Bandwidth -1.0 nm

Optical System - Double Beam, Grating 1200 lines/mm

Wavelength Accuracy - ± 0.1 nm

Wavelength Repeatability - ± 0.1 nm

Scanning Speed - HI, MED & LOW, MAX. 3600 nm/min

Photometric Accuracy - ± 0.3 %T or

                                                  ± 0.002 A/h@1A

Photometric Range - %T 0 - 200%

                                            Abs: -0.4 to 4A

                                            Cone.: 0 - 9999

Stray Light - < 0.05 %T @ 220 nm & 340 nm

Stability - ± 0.001 A/h @ 500 nm

Display -7 Inches 320 x 240 TFT coloured graphical LCD

Baseline Flatness - ± 0.001A/h (200 -1000 nm)

Sample Compartment - 2 cell holder 10 mm path- length. (50 mm & 100 mm path-length optional at extra cost)

Light Source - Halogen & Deuterium Lamps (Pre-Aligned)

Printer Interface - USB drive, USB host and RS 232

Detector - Silicon photodiode

PC Connectivity - USB Port for PC connectivity and RS 232

Power - 230 0 ±10% AC, 50 Hz

Dimensions (L x B x H) - 580 x 500 x210 mm (Approx.)

Weight - 16.0 Kg. (Approx)

INTERNAL CODE: - KD.2331.25614
