Double Beam UV-VIS spectrophotometer (Xenon Lamp) (Model No: HVO-2301)

Double Beam UV-VIS spectrophotometer (Xenon Lamp) (Model No: HVO-2301)


  • Rs. 539,110.00

Double Beam UV/VIS spectrophotometer (Xenon Lamp)

Advance circuit measurement and control system make the instrument of high reliability and low noise. Range 190-1100 nm, basic/ quantitative wavelength scan/DNA Protein Test/Kinetic, automatic peak picking & spectrum display. Large colored screen with graphic display. Spectrum and data can be printed out by printer and sent to computer via USB PORT. SOFTWARE INCLUDED


  • Function: Basic, Kinetics, Wavelength Quantitative, Scan, DNN Protein Multi Wave
  • Wavelength Range: 190-1100nm
  • Spectral Bandwidth: 1nm
  • Optical System: Double Beam, Grating 1200 lines/mm
  • Wavelength Accuracy: ±0.1nm
  • Wavelength Repeatability: ≤0.1nm
  • Scanning Speed: HI, Med & low, Max. 3600nm/min
  • Photometric Range:
                  %T: 0~200%
                  Abs: -0.3 to 3A
                  Conc: 0-9999C
  • Photometric Accuracy: ±03 % T or± 0.002A/h @1A
  • Stray Light<0.03% @ 220 & 360nm
  • Stability: ±0.001A/h @ 500nm
  • Display: 7 Inches TFT Colored Screen
  • Baseline Flatness: ± 0.001A/h (200 - 1000 nm)
  • Sample Compartment:  2 cell holder -10 mm path-length.
  • Light Source: Xenon Lamp
  • Output Ports: USB DRIVE,  USB HOST & RS232
  • Power: 230 V ± 10% AC, 50 Hz
  • Dimensions: Instrument 810x660x390mm (Approx.)
  • Weight: Instrument 27 Kg. (Approx.)


  • Double Beam Optics
  • 7 Inches TFT Colored Screen
  • Auto Wavelength Setting at 0.1 nm interval.
  • On-screen Standard and Kinetic Curve Display
  • Xenon Lamp for extend lifetime
  • Application Software provides complete control of this instrument from a computer through the built-in USB control Port
  • Basic, WL Scan, Multi-Wavelength, Kinetic, Quantitative, DNA/Proteinmodes.
