Double Beam UV-VIS spectrophotometer (Touch Screen)
Advance circuit measurement and control system make the instrument of high reliability and low noise. Range 190-1100 nm, basic/ quantitative wavelength scan/DNA Protein Test/Kinetic, automatic peak picking & spectrum display. Large Touch screen with colored display. Spectrum and data can be printed out by printer and sent to computer via USB PORT. SOFTWARE
TECHNICAL SPECIFICATIONS:
-
Function: Basic, Kinetics, Wavelength Scan Multi Wavelength Quantitative, Scan, DNN Protein
-
Wavelength Range: 190-1100nm
-
Spectral Bandwidth: 1.8nm
-
Optical System: Double Beam, Grating 1200 lines/mm
-
Wavelength Accuracy: ±0.1nm
-
Wavelength Repeatability: ≤0.1nm
-
Scanning Speed: HI, Med & low, Max. 3600nm/min
-
Photometric Range: 0~200%T, -0.3 to 3A, Conc. 0-9999C
-
Photometric Accuracy: ±03 % T or± 0.002A/h @1A
-
Stray Light: < 0.03% @ 220nm & 360nm
-
Stability: ±0.001A/h @ 500nm
-
Display: 10.1 Inches Colored Touch Screen
-
Baseline Flatness: ± 0.001A/h (200 - 1000 nm)
-
Sample Compartment: 2 cell -10 mm path-length.
-
Light Source: Halogen & Deuterium Lamps (Pre-Aligned)
-
Printer Interface: Parallel Port for Dot Metrix
-
PC Connectivity: USB Port for PC Connecticity
-
Power: 230 V ± 10% AC, 50 Hz
-
Dimensions: Instrument 810x660x390mm (Approx.)
-
Weight: Instrument 27 Kg. (Approx.)
SALIENT FEATURES:
- Double Beam Optics
- 10.1 Inches Colored Touch Screen
- Auto Wavelength Setting at 0.1 nm interval.
- On-screen Standard and Kinetic Curve Display
- Tungsten/Deuterium Lamp can be turn on/off to extend lifetime
- Application Software provides complete control of this instrument from a computer through the built-in USB control Port
- Basic, WL Scan, Multi-Wavelength, Kinetic, Quantitative, DNA/Proteinmodes.
- Pre-Aligned design makes it convenient to change lamps
|
