FTIR Spectrometer (Model: HVL: 4100)

FTIR Spectrometer

(Model: HVL: 4100)

Technical Specifications –

Fourier Transform Infrared Spectrometer is an independent

research and development of products, it is the most competitive

FTIR convenient installation, simple use.

- Wave number Range 7800 ~ 375 cm-1

- Interferometer Michelson interferometer with 30 degrees of incidence angle 100%-line tilt range Better than 0.5% (2200~1900cm-1)

- Resolution 1 cm-1

- Wave Number Repeatability 1 cm-1

- Wave Number Accuracy 0.01 cm-1

- Signal Noise Ratio 30000:1 (DLATGS, resolution@4cm-1. Sample and background scan for 1 min@2100cm-1)

- Detector High resolution DLATGS detector with Moisture-proof coating, Beam splitter KBr coated with Ge (Made in USA)

- Light Source Long-life, air-cooled IR light source (Made in USA) Electronic System A/D

- converter of 24 bits at 500MHz, USB 2.0

- Power 110-220V AC, 50-60Hz
