High-Capacity Magnetic Stirrer (Model No. HVO-STIR-100LTR)

HOVERLABS

Specification:

Brushless DC motor for quiet operation and maintenance free long operation
Microprocessor controlled stirrer with variable speed and time setting, along with last run memory function
Adjustable speed ranging from 100-800 RPM (100L), with increment of 10 RPM and accuracy of+/- 10 RPM
Long timer setting from 1 to 99 hours 59 minutes & infinite mode
Choice of acceleration rates from Al to A9
Programmable Pulse with direction change feature - Pulse timing can be set from 30 to 300 seconds
Stainless steel (SS) set up plate for corrosion protection
Automatic Power On in case of power failure, automatic run on remaining duration after power resumption
Power Overload safety feature
Supplied with stir bar and support frame for holding vessel
CE Certified

Technical Specification:

Motor Type: Brushless motor
Max. Capacity: 100ltr
Variable Speed: 100 - 800 RPM
Run Time: 1-99 hours 59 mins & infinite
Ramp Up Speed feature: User can select different Acceleration rates (Al-A9 with A9 being the fastest rate and Al slowest)
Pulse Mode: Alternating clockwise and anticlockwise motion with adjustable variable time 30-300 sec
Digital Display: Yes
Accuracy: ± 10 RPM
Product & Plate Dimensions (SS): 393 x 267 x 105 mm & 215 x 294 mm
Max. Stir bar length: 80mm
Protection class: IP 21
Structure frame size (With adjustable height): 504 x 500 x 164 mm
Weight: 5.5 Kgs
Voltage/ Consumption: 100-240V AC, 50/60 Hz
