High-Performance Liquid Chromatography (Model No. HV-6300)

Features :

• Improve the maximum limited pressure by precise tranducer
• Accord with GMP/GLP, ISO9001, 21 CFR Part II with CDS (Software)
• Online Washing Device while analysis
• Self - priming pump head requires no manual priming
• Available with micro, analytical, semi-prep, and prep pump heads
• Programmable solvent compressibility compensation
• Easy maintenance and service for all wetted parts

Specifications :

• Flow Range    :    0.001-9 .999 ml/min
• Delivery method    :    Double piston ( Main & Auxiliary )
• Pump head    :    10ml SST/Peek analytic al
• Accuracy    :    ± 1% or ± 2μL/min, whichever is greater / ± 1% or ± 1μL/min, whichever is greater (Micro)
• Flow rate settings    :    0 - 0.10 mL/min. 0.001 in c. , 0.10-0 .90 mL/min. 0.010 inc., 1.0 mL/min.+ 0.10 inc .
• Precision    :    0.1% RSD
• Pmax    :    9999 psi
• System connections    :    1/16’’ capillaries
• Dimensions    :    130 mm x 260 mm x 420 m m
• Weight.    :    11 kg
• Power input    :    85 to 264 VAC, 47 to 63 Hz, 60 Watts
• Display    :    300mm

UV-VIS Spectrophotometer Detector

Features :

• Unique pool structure ensures the accuracy and sensitivity of the instrument
• Easy maintenance a nd service for all wetted parts
• High-quality structure
• Long life deuterium lamp
• Easily replace
• Advanced design

Specification :

• Wavelength    :    190-700 nm
• Spectra l bandwidth    :    6 nm
• Wavelength Accuracy    :    ≤±1 nm
• Wavelength Reproducibility    :    ≤± 0.1 nm
• Flow pool volume    :    8μ L
• Optical path    :    10 mm
• Dynamic Noise    :    ≤± 0.75×10 5AU (Methanol, 1ml/min, 254nm, 20°C)"
• Static Noise    :    ≤± 0.5×10 5AU(Empty pool, Response time 1 s, 20 °C)"
• Dynamic Drifting    :    ≤±1×10 - 4AU (Methanol, 1ml/min, 254nm, 20°C )
• Static Drifting    :    20 °C) ≤± 0.5×10 - 4AU(Empty pool, Response time 1 s,"
• Qualitative repeatability    :    RSD ≤ 0.1%
• Quantitative repeatability    :    RSD ≤ 0.5%
• Dimensions130H x 260W x 420 D, (mm )
• Weight.11 kg

Standard Configuration :

• Liquid Constant flow Pump  :  2 set
• UV-VIS Spectrophotometric Detector   :  1 se t
• System Controller    :   1 set
• Mixer    :  1 set
• Injector    :   1 set
• Chromatography data sys tem :  1 se t
• Chromatography column    : 1 se t
