Features :
- Improve the maximum limited pressure by precise tranducer
- Accord with GMP/GLP, ISO9001, 21 CFR Part II with CDS (Software)
- Online Washing Device while analysis
- Self - priming pump head requires no manual priming
- Available with micro, analytical, semi-prep, and prep pump heads
- Programmable solvent compressibility compensation
- Easy maintenance and service for all wetted parts
Specifications :
- Flow Range : 0.001-9 .999 ml/min
- Delivery method : Double piston (Main & Auxiliary)
- Pump head : 10ml SST/Peek analytical
- Accuracy : ± 1% or ± 2μL/min, whichever is greater / ± 1% or ± 1μL/min, whichever is greater (Micro)
- Flow rate settings : 0 - 0.10 mL/min. 0.001 in c. , 0.10-0 .90 mL/min. 0.010 inc., 1.0 mL/min.+ 0.10 inc .
- Precision : 0.1% RSD
- Pmax : 9999 psi
- System connection s : 1/16’’ capillaries
- Dimensions : 130 mm x 260 mm x 420 mm
- Weight. : 11 kg
- Power input : 85 to 264 VAC, 47 to 63 Hz, 60 Watts
- Display : 300mm
UV-VIS Spectrophotometer Detector
Features :
- Unique pool structure ensures the accuracy and sensitivity of the instrument
- Easy maintenance a nd service for all wetted parts
- High-quality structure
- Long life deuterium lamp
- Easily replace
- Advanced design
Specification :
- Wavelength : 190-700 nm
- Spectral bandwidth : 6 nm
- Wavelength Accuracy : ≤±1 nm
- Wavelength Reproducibility : ≤± 0.1 nm
- Flow pool volume : 8μ L
- Optical path : 10 mm
- Dynamic Noise : ≤± 0.75×10 5AU (Methanol, 1ml/min, 254nm, 20°C)"
- Static Noise : ≤± 0.5×10 5AU(Empty pool, Response time 1 s, 20 °C)"
- Dynamic Drifting : ≤±1×10 - 4AU (Methanol, 1ml/min, 254nm, 20°C )
- Static Drifting : 20 °C) ≤± 0.5×10 - 4AU(Empty pool, Response time 1 s,"
- Qualitative repeatability : RSD ≤ 0.1%
- Quantitative repeatability : RSD ≤ 0.5%
- Dimensions : 130H x 260W x 420 D, (mm )
- Weight.11 kg
Standard Configuration :
- Liquid Constant flow Pump : 2 set
- UV-VIS Spectrophotometric Detector : 1 set
- System Controller : 1 set
- Mixer : 1 set
- Injector : 1 set
- Chromatography data sys tem : 1 set
- Chromatography column : 1 set
|
