HORIZONTAL AUTOCLAVE (Model: HVL-130)

HORIZONTAL AUTOCLAVE

(Model: HVL-130)

Technical Specifications –

Construction

Inner chamber is made of thick Stainless-Steel Sheet of 304 quality

and jacket is made out of Stainless-Steel Sheet. The door is made of

thick high-grade Stainless-Steel plate, the unit is hydraulically

tested to withstand pressure up to 40 psi, Inner chamber and

steam jacket is made of heavy gauge Stainless Steel sheet with

leak proof argon arc welding

Steam Generator (Boiler)

Made of thick stainless-steel sheet suitably located under the

sterilizer, High grade flanged immersion type heaters are fitted at

the backside, Fitted with Water Level, Safety Valve, Water Inlet and

Drain Valves, it is also provided with Low Water Level cut off

device to protects the heater from

burning out dry, the steam pressure in the boiler is indicated on a

individual pressure gauge

Pressure Control

The “PIEZOSTAT” (Pressure control device) is incorporated in the

unit as it economises on power consumption and reduces the

frequent opening of the steam release valve and

thus prevents the release of steam in the room, it cuts off the

power supply to heaters when the set pressure is achieved and reenergizes the heating elements when pressure

falls below the set point.

Safety Door

Sterilizer has hinged self-locking single piece thick SS plate door and cannot be opened when under pressure. The self-locking device automatically disengages the piston mechanism when the sterilizer is under pressure to preclude any eventuality of accident- Inner Dimension: 600 x 600 x 900mm (24” x 24" x 36”) (Length x Breadth x Depth)- Capacity: 320 litres. - Heater Load: 9.0 KW- Door at Back (Double Door)

INTERNAL CODE: - KD. -2265.25614
