COD DIGESTER (Model: HVS- COD70)

“HOVERLABS” COD DIGESTER

(Model: HVS- COD70)

TECHNICAL SPECIFICATION:

- Body made out of thick mild steel finished with powder coating.

- Heating blocks made of Aluminum die casting with suitable holes to hold glass tubes.

- Temperature range from ambient to +5 deg C -150 deg C with accuracy of +1 deg C.

- Sensor - RTD (PT-100) Material External powder coated CRC steel. .

- Designed with glass reaction vessels and air condensers.

- Supplied with stand to accommodate vessels.

- Temperature is controlled by Dual Display Microprocessor PID Digital Temperature Indicator cum Controller & 0-999 minutes Digital Timer.

- Display LED with set value (SV) and process value (PV)

- Supplied with Glass Tubes 15 nos. Glass Tube Dimension: 38 mm dia x 200 mm Depth.

- Glass Tube Size: Compatible to fit in heating block and suitable for digestion of 60-80 ml of reaction mixture.

- Air Condenser: 15 Nos. 600 mm height (Apprx.)

- Spares & Consumables:

- Suitable glass tubes 15 nos., Aluminum Polished Block, Air Condensers 15 nos., Tube Stand 2 nos., with minimum 15 holes each, Condenser stand 2 nos. with 6 position to hold the supplied condenser

- Suitable to working on 220V AC 50Hz single phase.

- Supplied complete Working Operation Manual.

INTERNAL CODE: - KDSM.2259.24919
