Microtome automated (Model: HLS-MCR-200)

“HOVERLABS” Microtome automated

(Model: HLS-MCR-200)

TECHNICAL SPECIFICATION:

• It has precise stepper motor and drives which ensure accurate specimen advance and maintenance-free cross roller guide ways which provide greater stability during sectioning.

• It has a powerful sectioning motor and sectioning speed can also be adjusted.

• LCD screen displays section and trimming thickness, number of sections cut, travel. Trimming thickness, sectioning thickness, fast forward and fast backward movement can be controlled through feather-touch keypad. The hand wheel has lockable in any position, huge-volume waste tray. It has an integrated safety alarm system and emergency stop button.

• It has Section Thickness Range 0.5–200 μm. (You can set up to 200 μm, can change as per your requirement.)

• It has Section Thickness Setting:

 0.5–5 μm in 0.5 μm increment

 5–20 μm in 1 μm increment

 20–60 μm in 5 μm increment

 60–100 μm in 10 μm increment

 100–200 μm in 20 μm increment

• Trimming thickness setting – 1–900 μm (You can set any as per your requirement)

• Setting values:

 1–10 μm in 1 μm increment

 20–50 μm in 5 μm increments

 50–100 μm in 10 μm increment

 100–600 μm in 50 μm increment

 600–800 μm in 100 μm increment

• It has sectioning modes: 4 continuous, step, programmed, manual.

• Motorized Coarse Feed: 300 μm, 600 μm and 900 μm

• It has Horizontal Feed 30 mm.

• It has Vertical Specimen Stroke 70 mm.

• Sectioning speed adjustable, 3 different speeds: slow, medium and high

• Specimen retraction 5–100 μm in 5 μm increments, can be turned off

• Max specimen size 50 × 50 mm

• Specimen orientation: Horizontal 8°, Vertical 8°, Z 360°

• Nominal supply voltages 110/220 V AC ± 10%

• Nominal frequency 50/60 Hz

• Dimensions (basic instrument): 590 × 345 × 290 mm (W × D × H)

• Maximum operation automated

INTERNAL CODE: - KD. 6885169.251113
