“HOVERLABS” TISSUE CULTURE MICROSCOPE (Model: HVS-110A)

“HOVERLABS” TISSUE CULTURE MICROSCOPE

(Model: HVS-110A)

TECHNICAL SPECIFICATION:

- Optical System: Infinite Optical System

- Viewing Head: Trinocular Siedentop Head 45 Degree inclined with IPD 48-75mm.

- Eye Guards: Adjustable rubber Eye guards for comfortable viewing.

- Eyepieces: High Eye-point Plan Eyepiece 10X/22mm (Anti-fungal and Anti reflection coated), Centring Eyepiece

-  Nosepiece: Quintuple Revolving Nosepiece with click stop mechanism.

Objectives:

Infinity L.W.D Plan Achromatic Objective 4X

Infinity L.W.D Plan Achromatic PH 10X

Infinity L.W.D Plan Achromatic PH 20X

Infinity L.W.D Plan Achromatic PH 40X

- Mechanical Stage: Fixed Stage + Attachable Mechanical Stage with size 180mmx155mm, movement range: 80mmx50mm

- Focussing: Co-axial Coarse and fine focussing with 0.2mm/rotation

- Condenser: Fixed ABBE Condenser N.A 0.3 with frosted white / Blue Filter along with phase slider.

- Illumination: 5W Led Light (Upto 50,000 Working hours) with intensity controller.

- Power: Universal Power supply 110v-240v integrated with voltage flux stabilizer.

- Accessories: Slide holder, well plate holder, Petridis holder, c-mount Adopter, Dust Cover, power cord.

- Packaging: Inner Thermocol / Styrofoam Packing and outdoor cardboard Box

INTERNAL CODE: - KD. 2371.251118
