“HOVERLABS” Water Bath (Model: HVS-WB458)

“HOVERLABS” Water Bath

(Model: HVS-WB458)

TECHNICAL SPECIFICATION:

FUNCTIONAL REQUIREMENTS:

The Water used for pre-heating milk samples at our BMCs. It suitable for laboratory heating applications such as sample incubation, chemical reactions, quality control testing, and dairy laboratory analysis.

2.1 Technical specifications

2.1.1Type

• Digital Laboratory Water Bath, microprocessor based PID controlled.

2.1.2 Construction

• Inner chamber made of stainless steel (SS 304) make JSW

• Outer body made of stainless steel (SS 304) make JSW

• Double-walled construction with high grade glass-wool insulation to minimize heat loss.

2.1.3 Outer Size

• Minimum 670mm by 330 mm by 320 mm height.

2. 1.4 Temperature Range:

• Ambient +5°C to 100°C

Technical Specifications:

2.1.5 Temperature Indicator Cum Control

• Microprocessor / PID based digital temperature Indicator cum controller with temperature

setting and display in °C. It Digital LED display for set temperature and actual temperature.

Make: Omron.

2.1.6 Temperature Accuracy & Uniformity

• Accuracy: ±0.5°C or better with Uniform heating across the bath

2.1.7 Heating System

• Stainless Steel (Concealed) Heating Element: Heating element enclosed within a

stainless-steel sheath and fitted below the bath base (not directly exposed).

2.1.8 Safety Features

• Over-temperature protection

• Low water level cut-off

• Thermal fuse for heater protection

2.1.9 Power Supply

• 230 V ±10%, 50 Hz, Single phase, suitable for Indian power conditions

2.1.10 Accessories

• Stainless steel (SS-304) lid (plain or concentric ring type)

• Stainless steel (SS-304) tray / perforated platform

2.1.11 Standards & Compliance

• Equipment comply with relevant BIS / ISO standards

• Make ISO 9001 certified

2.1.12 Warranty

• Minimum 12 months warranty from date of installation

INTERNAL CODE: - KD. 2394.2624
