Infrared Thermal Imaging Camera (Basic Type) (Model No. HVO-9132-T400)

HOVERLABS

Rs. 75,302.00

Free Shipping | No Packaging Charges | Click for Delivery Schedule | G.S.T@18% Extra

Infrared Thermal Imaging Camera (Basic Type)

Specification:

IR Image

IR resolution: 120X90@17µm

Detector type: VOx/7.5~14µm

Frame rate: 25Hz/9Hz

Thermal sensitivity/NETD: 60mk

Focal length: 2.28mm/F1.13

Field of view (FOV): 50°X38°

Spatial Resolution (IFOV): 7.6mrad

Focus: Focus-free

Visible Camera

Visible camera resolution: 320x240, focus-free
Flashlight: Yes

Image Display

Display: 2.4 inch IPS technology TFT display
Display Resolution: 320x240
Image model: IR/visible/picture-in-picture
Color palettes: 6: white hot, iron red, hot iron, arctic, rainbow 1, rainbow 2

Temperature Measurement

Temperature range: -20~150°C, 100~400°C (auto switching)
Accuracy:

±2°C or ±2%, whichever is greater

(target temp ≥0°c, ambient temp is 15~30°c)
Measurement spot: Center Spot
Measurement area: 3(incl. max & min temp)
Auto max & min spot tracking: Yes
Alarm: Full screen max & min spot alarm

Image Storage

Storage media: TF card (16G)
IR image format: full radiometric (JPG) (120X90)
Visible image : YES, 320X240

Connections & Communications

USB: Type~ C, TF card slot

Tripod interface: Yes

Mobile App: Yes

PCIR analysis software: Yes

Power System

Battery type: Rechargeable li ion battery

Battery operation time: >5 hours

Charging time: internal charge, ≤2.5 hours

Environmental Parameters

Operation temperature: -10~50°c

Storage temperature: -40~70°c

Protection: IP54, 2-meter drop test

Certification: CE/ROHS/FCC

Dimension (L x W x H): 194x61.5x76mm

Weight: 350g

Features:

IR/visible/laser indicator
Trigger button for photo taking
2-meter drop test, IP54 protection

Standard Delivery:

Main Unit: 1Pc
Power Supply Adapter
TYPE-C Cable: 1Pc
16G TF Card: 1Pc
