Inverted Tissue Culture Microscope (Model No: HV-1515)
Inverted Tissue Culture Microscope
Specification
Trinocular Inverted Tissue Culture Microscope with quadruple revolving nosepiece, equipped with binocular observation head and best quality optical components having full prismatic optical path, large co-axial mechanical stage of size 165mm. x 180mm., co-axial coarse & fine focusing knobs with adjustable tension control ring, variable intensity controlled built in base solid-state transformer, fitted with 6V 20Watts halogen bulb and illumination based on system.
- Supplied with following optical combination in a storing box.
- Size: Standard,
- Observation Head: 45° inclined Trinocular head,
- Nosepiece: Quadruple revolving turret nosepiece with positive accurate click stops. Stage: Oversize plain stage 180 x 165mm with 2 extension plates for large bottles and micro filter work.
- Illumination: Based on Koehler's system is provided by a post-mounted high intensity 6 volts 20 watts Halogen illuminator.
- Objectives: Achromatic LWD 4X, 10X, LWD 20X & LWD-40X.
- Eyepieces: HWF 10x (paired) with eye guards.
Product Internal Code: 8615
